Yamato Scientific Co., Ltd. 冷凍乾燥機 DC801

Specification

• Performance
• ▼ Trap cooling temperature: -85°C
• ▼ Amount of dehumidification: 1.0 L
• ▼ Operating ambient temperature range: 5~30°C
• Configuration
• ▼ Temperature Sensor: Pt100Ω
• ▼ Temperature display: 7-segment LCD * The temperature of the display is the surface temperature of cooling piping.
• ▼ Freezer: Air-Cooled 350 W
• ▼ Refrigerant/Amount of Refrigerant: R600a Other Mixed Refrigerants
• ▼ Achievement meter: high and low pressure monitors
• ▼ Water Tank Shape/Material: Cylindrical/Stainless Steel Plate
• ▼ Drain: Vacuum Hose with Plug
• ▼ Vacuum Gauge: Pilani Vacuum Gauge
• ▼ Defrosting mechanism: hot gas bypass system
• ▼ Exhaust Port (Vacuum Pump Connection Port): φ17 mm
• ▼ Service Outlet: Max 6A for Vacuum Pump/Max 2A for Heater
• Features: Trap Thaw: Hot Gas Thaw
• Safety devices: overcurrent earth leakage breaker, refrigerator overload relay, check valve
• Standard
• ▼ Trap Size: φ153 x Height 235 mm
• ▼ Internal Volume: Approx. 4 L
• ▼ Displacement of Applicable Vacuum Pump: 50/60L/min
• Accessories: Vacuum Silicon Grease, Vacuum Hose, Fuse 10 A, Caster Fixing Folder 4 Pieces
• External Dimensions (Width x Depth x Height): 405 x 500 x 846 mm
• Power Capacity: 100 VAC 7 A, Breaker Capacity and 20 A Supply Capacity
• Weight: 65 kg
