Since it is mass thermoregulator of max. 25A, control of large-sized heater etc. is possible.
Since it is 100V, 200V combination, possible to use it broadly in one set.
Timer set of 3 patterns is possible.
Both K type thermo couple and Pt100ohm can be used factory setting is K type thermo couple .

Model number: TXN-25A
Temperature settings range (Pt sensor/K class thermocouple): 0.0 - 200.0 /0 - 500 .
Temperature control system: PID control, SSR output
Connection capacity: AC100/200V 25A
Timer type: Autostart, auto-stop, SV start
Timer setting available time: 1 minute - 99 hours 59 minutes
Temperature indication accuracy: +/- 2 or +/- 0.3% + 1 digit, whichever is larger
Output: Control voltage output/AC100/200V 25A, Alarm contact output/AC100/200V 2.4A
Power cord: Non (connected to power terminal on the back terminal block)
Safety device: Overcurrent breaker
Size: 190 x 239 x 220mm
*Sensor is not included in the package. Please select one of the shape, type according to the application (no connector type).
*Power cord is not included. Please prepare according to used power voltage.
