Insulation board is placed on stainless steel top plate, which enables stirring while oil bath is placed on it.
With strong magnet and induction motor, possible to stir high viscosity and large capacity liquid.
Feedback control by tacho generator, provides stable rotation from low speed to high speed.
It provides stable rotation even in low rotation speed range.
Adjustment dial is analog type that can set speed in proportion to dial scale.
Dedicated fixing bracket can be attached on the back side, and by combining with support rod, it can be used as stand.

Material: Body/SPCC (acrylic paint), Top plate/Stainless steel (SUS 304)
Motor: Induction motor
Variable speed system: Feedback control by taco generator
Load capacity: 22kg
Top size: 200 x 200mm
Speed: 60 ~ 1350 rpm
Motor: 15W
Stirring capacity: 20L
Magnet/Strength (T): Samakoba/0.37
Power supply: AC100V 50/60Hz, 2.5m 3P plug
Maximum power consumption: 40W
Body size: 200 x 200 (211) x 152mm (including protrusions inside ())
*Stirring capacity and number of revolutions are for water.
Weight: 5.0kg
*The size of the stirrer used depends on its capacity and viscosity. Use it for different purposes.
