Feature

Tester with data communication function (5999 count). Compared to the cheaper LDM-81D, it has improved accuracy by 3 to 5/6 digits (5999 counts), added communication functions, and enhanced voltage limits and bar graph display functions. (It is not a simple forward compatibility, so please compare the detailed specifications carefully.) The logging data is acquired by the communication function with the PC, and data processing by the PC is possible. (Software included.)
Tester. Compared to the cheaper LDM-81D, the upper voltage limit and bar graph display functions are expanded. It can measure frequencies up to the 20 MHz range. The ability to connect to a PC is added so that logging data can be retrieved. Data processing on a PC is possible.
[Measurement Range]
DC voltage 600 m/6/60/600/1000V
AC voltage 6/60/600/750V (average value display)
DC current 600μ/6 m/60 m/600 m/6/10A
AC current 600μ/6 m/60 m/600 m/6/10A
Resistance 600/6k/60k/600k/6M/60 MΩ
Capacitance 40n/400n/4μ/40μ/200 μF
Frequency 100/1k/10k/100k/1M/20 MHz
Temperature -20~400°C/400~1000°C/0~1832 °F
hFE0~1000
Diode test/conduction check function
Auto/manual range switching function, Auto power off function
3 • In addition to the large 5/6 digit 7 segment LCD display, the 61 digit bar graph scale display and unit code display are also available.
Comes with a PC USB cable and software CD-ROM. Can be recorded, analyzed, printed out, etc.
Operates with two AAA batteries.
Download for MiniUSB connection: handcomNEWV0.2_0.3_0.4_20141021.zip [1.75MB]
