It is a high-end model that takes into consideration the use of various types of concentration, distillation, evaporation, and drying, from laboratory classes of testing, research, and inspection to production fields.
With the adoption of an electric jack, up and down movement of the bus has become easy with only button operation.
A stable vacuum is obtained by using a mechanical seal with a long history.
The LED digital display panel makes it easier to see.
It has an emergency stop button just in case.
In the event of an abnormality such as a power failure caused by a safety device, there is a function to stop operation safely.

Temperature Adjustment Range: R.T. + 5 ° C, to 180 ° C (Water and Oil common use)
capacity : 360 mm x 180 mm 18 L SUS304
Bus Lifting: Electric Stroke 238 mm
Rotating Part (rotational speed range): 10 to 150 rpm
Vacuum attainment level of glass part: 2 hPa
Rotary Flask: 10 L (Neck inner diameter 100 mm)
Receiving Flask: 5 L, with Drain Valve
Display: 7-segment LED digital display (rotation speed, bus temperature, steam temperature)
Operating Temperature Range: 5 to 35 ° C
Operating Humidity Range: 10 to 90% rh (No condensation)
power supply: 200 VAC to 240 V (single phase) 3.2 kVA power supply Cable 3 m
Dimensions (main body only) : 1040 ( W ) x 520 ( D ) x 1700 ( H ) mm (Not including glass parts)
Mass: about 90 kg (Not including glass parts)
Code Number: 050340 -100
