THINKY CORPORATION 消泡裝置 (真空型) ARV-310P

Features

• With the rotation system and vacuum depressurization function, high-precision defoaming is possible in a short time without spillage during operation.
• Simultaneously processes agitation and dispersion and submicron level bubble removal.
• Vacuum setting of 0.1 kPa units and processing considering saturated vapor pressure are possible.
• Progress and operation status are displayed on the touch panel in real time. You can register 20 recipes.
• Setting conditions can be selected and operation can be started and stopped by the communication function (RS-232 C connection).
• A function that reports processing information to external terminals every second contributes to improved traceability.
• Sample source code (Python) for using the communication function is included.
• Because the communication protocol is open to the public, customers can freely design software for external terminals.

Specification

• Method: Vacuum type, rotating/revolving propeller-less mixing method
• Maximum Load Capacity: 310 g
• ▼ *The total mass when the cup holder is loaded including ingredients, containers, adapters, etc.
• Standard Container: Internal Volume 300 mL and 150 mL, Made of HDPE
• ▼ *The actual stirring amount depends on the container, material and conditions, so please contact us.
• supply power
• ▼ Voltage: 100 VAC ±10%%%% single phase, 50/60Hz
• ▼ Power consumption: approx. 50VA (standby), max. 1200VA (operating)
• Safety mechanism: door sensor, vibration sensor, rotation sensor
• Transport locking mechanism: front and rear (one each)
• ▼ *It will be shipped and delivered in the locked state. Deactivate before use.
• Body External Dimensions: 555 x 645 x 450 mm
• Body mass: Approx. 90 kg
• Accessories: Owner's Manual, AC Cable, HDPE 300 mL Container x 3, 150 mL Container x 1, Perforated Inner and Outer Lids for 300 mL Container x 3 Each, 150 mL Container x 1 Each, Adapter for 150 mL Container x 1, Box Wrench, Hex Wrench, Pliers, Vacuum Pump Oil, Waste Oil Receiver, Logo
