AS ONE Corporation 科學高壓滅菌鍋 (16 公升) 附出貨前檢驗文件 NCC-16LV

Features

• Small autoclave suitable for research institutions.
• Sterilization is performed with two temperature settings, and continuous sterilization in a short time is possible.
• Semi-automatic model with microcomputer control.
• Timer can be set.

Specification

• Temperature Setting: 121°C/132°C
• External Dimensions (mm): 330 x 340 x 510
• Can Capacity: Approx. 16 L
• Can Size: φ240 x 360 mm
• Sterilization Pressure: (121°C) 0.1 MPa, (132°C) 0.2 MPa
• Timer Settings: (121°C) 20 to 99 minutes, (132°C) 5 to 99 minutes
• Pressure Gauge: Bourdon Tube Type, 0~0.4 MPa
• Control system: microcomputer control system
• Safety Device: Empty Heating Prevention Device, Safety Valve, Overcurrent Protection Device, Leakage Protection, Door Lock Detection, Excess Temperature Rise Protection
• Material: Body Exterior/Steel (Baked Paint), Can Body/Stainless Steel (SUS304)
• Power: 100 VAC 50/60Hz 1200 W
• Weight: Approx. 26 kg
• Accessories: Net Basket (Inner Dimension φ190 x 265 mm), Shelf Board, Drain Tube (2 m)
• *This product is not a medical device. Please use it for research and development purposes.
• *Cannot be used for sterilization of medical instruments, etc.
• Model Number: NCC-16LV
