MEITOU KAKOUKI Diaphragm Quantitative Pump (50Hz) 25 - 250mL/Min (60Hz) 30 - 300mL/Min Vinyl Chloride Resin　MEX-250

Name: MEITOU KAKOUKI Diaphragm Quantitative Pump (50Hz) 25 - 250mL/Min (60Hz) 30 - 300mL/Min Vinyl Chloride Resin MEX-250
Brand: MEITOU KAKOUKI
SKU: IABP-164713
Price: 64571 TWD
Availability: InStock
Rating: 5 (77 reviews)

IABP-164713

詢價商品

請諮詢取得報價及交期

Maximum flow rate (Liquid)

300mL/min、250mL/min

原廠型號

MEX-250

選擇包裝

1piece

期貨16~30工作天

購買數量

訂購諮詢

查看其他型號

量大殺價

付款方式

月結報帳 / 信用卡 / 銀行轉帳

運送方式

宅配快速到貨，滿 NT$ 999 元即享免運！

商品介紹

Feature

The flow rate can be adjusted step by step regardless of whether it is in operation or stopped.
Planetary gear two-stage deceleration allows continuous operation for a long time.
Uses aluminum inside, so it's lightweight.

Specifications

Model number: MEX-250
Discharge quantity (mL/min): 25 - 250
Discharge quantity (mL/min): 30 - 300
Maximum pressure (MPa): Approximately 0.69 (7kg/cm2)
Pump head material/connection hose diameter(φmm): PVC (vinyl chloride resin)/6 x 11
Suction head: 2m
Available liquid viscosity: 300mPa・s
Liquid junction material Diaphragm: PTFE (poly tetrafluoroethylene), O-ring: Viton, Head, included hose: PVC (vinyl chloride resin)
Weight: 12kg
Power supply: AC100V 65W
Accessories: Hose 4m
*It can be installed in safety explosion-proof motor, pressure explosion-proof motor, different voltage motor, etc. Please contact with us.
